DS-160W
$259
Offering the Klipsch Signature Horn-Loaded performance at an incredible value, the DS-160W features a 6.5” Polypropylene woofer and a 1” Silk Dome tweeter mated to a round Tractrix® horn for dynamic acoustic performance. Utilizing the Sky Hook® patented Cinch by Swarm Installation System, your install time is reduced by 75%.
Features
Key Product Features
| 6.5” Polypropylene woofer |
| 1” Silk Dome tweeter |
| Patented Sky Hook® Tool-Free Installation System |
| Bezel-Free Magnetic Grille |
Specifications
Key Product Specifications
| Frequency Range | 77Hz - 20kHz +/- 3dB |
| High Frequency Driver | 1" (2.54cm) Silk Dome Tweeter mated to a round Tractrix® Horn |
| Low Frequency Driver | 6.5” (16.51cm) Polypropylene Woofer |
| Sensitivity | 91 dB @ 2.83V / 1m |
| Coverage Angle | 100° |
| Power Handling | 50W RMS / 200W RMS |
| Impedance | 8 Ohm Compatible |
| Enclosure Type | ABS/Infinite Baffle |
| Finish | Black Baffle/Frame, White Paintable Grille |
| Product Dimensions | 9.0” W x 14.1” H x 3.9” D (22.8cm H x 35.8cm W x 9.8cm D) |
| Mounting Depth | 3.78” (9.6cm) |
| Cutout Dimensions | 13” H X 8” W (33.0cm H X 20.3cm W) |
| Product Weight | 7.2lbs (3.25kg) |
| Included | Magnetic Grille |
| Installation Kit | IK-650-W II (Sold Separately) |
| Fire Rated Enclosure | ME-650-W (Sold Separately) |
Documents
Spec Sheet
For more technical detail, download the Spec Sheet here:
DS-160W Spec Sheet
.
Product Manual
Download the Product Manual for DS-160W here:
Designer Series Manual
.
